HK1 - M

HK1-M

Concentration- and moisture measurement

  • sate of the art microwave engineering
  • modular setup of evaluation unit and sensors
  • no moving parts
  • no wear
  • vibrations do not have an influence on the result of measurement
  • maintenance-free
  • optional remote control from a PC or separate operating device
  • up to 16 different calibrations
  • temperature sensor PT100 is standard, optional NTC possible





Due to the robust and modular design the microwave measuring instrument HK 1-M is particularly suitable for the measurements of concentration and water content in the food- , primary and chemical industry.


Depending upon operational area following antennas are used: We advise you gladly which antennas for which application or measuring kind the best results supply.

Technical data:
Measuring procedure Microwave engineering ISM-Band
Housing:
   Size LxWxH
   Enclosure
   Color
pressure cast aluminium housing
230 x 200 x 110mm
IP65 / NEMA 4
RAL 5024
Connections
   Power supply
   2 Analog outputs
   1 Analog input
   Temperature sensor
   PC interfaces
   1 Relays contact
   4 Digital inputs

   PROFI-BUS-DP

100-240V AC, optional 24V DC
0/4 - 20 mA
0/4 - 20 mA
PT 100, optional NTC possible
RS 232 or optional RS 485
max. 5A/250V
ext. select of 16 products / start / stop
such as for pressure compensation
optional
User interface
   Operating
   Display

6 integrated soft keys in keypad
2 x 24 characters illuminated
Sonsors / Antennas Pin antennas
Horn antennas
Spiral antennas
3A-spiral antennas
Short 3A pin antennas
Mini-spiral antennas
Ambient conditions
   Environment temperature
   Product temperature

-20°C to +85°C
 >0°C to +130°C (on request +140°C)

HK4 NIR spectralyser

HK4

Measurement of up to 4 organic components

  • simultaneous online- mesaurement of up to 4 organic components (e.g. fat, water, protein, connective tissue protein)
  • specially developed NIR (Near InfraRed) technology with diode array and therefore the first online NIR- spectrometer.
  • modular setup of evaluation unit and halogen sensor
  • transmission or reflection halogen sensor
  • no drift of the measurement values through aging of the lamps
  • independent of color changes
  • no moving parts


Trophy 2006    Innovation award:
The NIR-online-spectrometer HK4 was awarded by CFIA in France with the highest trophy measurement instruments can get in the food industry. At present the HK4 is the only online-spectrometer, to be used in raw process environment, not only in laboratories. The HK4 is developed with the latest online NIR technology with diode array and therefore directing in NIR technology.

Depending upon operational area different sensors are available.

Technical data:
Measuring procedure NIR spectrometer with diode array
Housing:
   Size LxWxH
   Enclosure
stainless steel housing
600 x300 x 167mm
IP65 / NEMA 4
Connections
   Power supply
   6 analog outputs
   1 Relays contact
   Temperature sensor
   PC interfaces
   PROFI-BUS-DP
   Digital inputs

85-265V AC, optional 24V C
0/4 - 20 mA
max. 5A / 230V
PT 100
RS 232 or RS 485
optional
Ext. Start / Stop
User interface
   Operating
   Display

6 integrated soft keys in keypad
2 x 24 characters illuminated
Sensors NIR-Sensor reflection
NIR-Sensor transmission
Software Chemometric Software Specter
Ambient conditions
   Environment temperature
   Product temperature

-20°C to +40°C
 >0°C to +70°C
